Peripheral neuropathy is a commonly encountered disorder in both the primary care and podiatric clinical settings. Peripheral neuropathy affects the nerves, which impairs sensation, movement, gland or organ function, and other aspects of well-being, including mental health. Peripheral nerve disorders affect 2.4% of the population, and prevalence increases with advancing age. Among the many types of peripheral neuropathy, diabetic peripheral neuropathy is the most common in the U.S. population.1 Nearly one-half of patients with diabetes will develop peripheral neuropathy.1,2 The American Diabetes Association issued a statement about the different types of peripheral neuropathies and the best ways for patients to control symptoms, with tight glycemic control being the most important factor.
Peripheral neuropathy is subdivided into three types: mononeuropathy, mononeuropathy multiplex, and polyneuropathy. Mononeuropathies are caused by an injury to a single nerve, such as a common peroneal nerve injury in the leg. These are usually acute findings following trauma. Mononeuropathies also can occur from a vasculitis or focal ischemia, but they usually manifest as mononeuropathy multiplex, in which two or more mononeuropathies arise simultaneously.3 This type of neuropathy often is secondary to a connective tissue disorder, underlying vasculitis, infections, or metabolic conditions.
Diabetic peripheral neuropathy is the leading cause of polyneuropathy, but more than 100 other causes of peripheral neuropathy exist.2 Despite the cause, its progression leads to loss of protective sensation, skin ulcerations, and chronic wounds, which in turn cause soft tissue and bone infections requiring amputation. All of these scenarios depend on the type of glycemic control of the patient, and vary by severity. Diabetic foot ulcers and their complications were estimated to cost U. S. healthcare payers $11 billion in 2001.4 Prevention, ultimately by understanding the pathophysiology of neuropathy and understanding the biomechanics of gait in relation to the foot, has been proven to significantly decrease morbidity with this disease.4
Manifestations of neuropathy result from disrupting normal functions of the peripheral nerves. There are three main types of nerves: 1) motor nerves, which control muscles and voluntary movement; 2) sensory nerves, which transmit signals from specialized receptors in the skin, joints, and internal organs; and 3) autonomic nerves, which control involuntary functions, such as blood pressure, heart rate, sweating, and the bowel and bladder.
Anatomy of Peripheral Nerves
Peripheral nerve fibers are grouped based on the diameter, signal conduction velocity, and myelination state of the axons. These classifications apply to both sensory and motor fibers. Fibers of the A group have a large diameter, high conduction velocity, and are myelinated. (See Tables 1, 2, and 3.) The A group is further subdivided into four types (A-alpha, A-beta, A-delta, and A-gamma fibers) based on the information carried by the fibers and the tissues they innervate.
- A-alpha fibers are motor and are the primary receptors of the muscle spindle.
- A-beta fibers are sensory, act as secondary receptors of the muscle spindle, and contribute to cutaneous mechanoreceptors.
- A-delta fibers are free nerve endings that conduct painful stimuli related to pressure and temperature.
- A-gamma fibers typically are motor neurons that control the intrinsic activation of the muscle spindle.
Fibers of the B group are myelinated with a small diameter and have a low conduction velocity. The primary role of B fibers is to transmit autonomic information.
Fibers of the C group are unmyelinated, have a small diameter, and have low conduction velocity. C fibers are considered polymodal because they often can respond to combinations of thermal, mechanical, and chemical stimuli and, therefore, are considered multi-use. A-delta and C fibers both contribute to the detection of diverse painful stimuli. Because of their higher conduction velocity, A-delta fibers are responsible for the sensation of a sharp, initial pain and respond to a weaker intensity of stimulus. These nerve fibers are associated with acute pain and, therefore, constitute the afferent portion of the reflex arc that results in pulling away from noxious stimuli. An example is the retraction or one's hand from a hot stove. Slowly conducting unmyelinated C fibers, by contrast, carry slow, longer-lasting pain sensations.3
Nerve axons are further subdivided into large and small fibers. Large fibers (A and B group) are insulated with a myelin sheath that allows for more rapid conduction of the electrical impulse. The large nerve fibers transmit motor signals to the muscles and sensory signals that convey vibratory sensations or proprioceptive information. The small nerve fibers (C group) are non-myelinated and are slower in conducting and transmitting signals from pain receptors in the skin. They also form the autonomic fibers that send signals to and from the internal organs. Neuropathies can be classified as demyelinating or axonal, small or large fiber, motor or sensory, or mixed.
Table 1. Overview of Peripheral Nerve Function |
|
|
Peripheral Nerve Type |
Function |
|
Motor |
Muscles, voluntary movement |
|
Sensory |
Transmit signals from skin, joints, and organs; sensations including pain and pressure |
|
Autonomic |
Involuntary functions, blood pressure, heart rate, bowel movements, bladder emptying, digestion |
Table 2. Group A Nerve Anatomy |
||
|
A Group |
Primary Receptor |
Secondary Receptor |
|
A-alpha |
Motor |
Muscle spindles |
|
A-beta |
Sensory |
Secondary muscle spindles |
|
A-delta |
Free nerve endings |
Painful stimuli |
|
A-gamma |
Motor |
Intrinsic muscle spindle |
|
Primary receptor implies information nerves carry; secondary receptor is the tissues they innervate. |
||
Table 3. Fiber Composition of Peripheral Nerves |
||||
|
Group |
Diameter |
Signal Conduction Velocity |
Myelination |
Function |
|
A |
Large |
High |
Yes |
Sharp initial pain, others |
|
B |
Small |
Low |
Yes |
Autonomic transmission |
|
C |
Small |
Low |
No |
Long-lasting pain |
Signs and Symptoms of Peripheral Neuropathy
The symptoms of neuropathy depend on the type and distribution of the nerves that are affected. Initially, symptoms can be subtle and hard for patients to describe. The American Diabetes Association has developed guidelines for patients to monitor symptoms of peripheral neuropathy. Many early signs of neuropathy are ignored or attributed to normal aging. It is critical to recognize the initial symptoms of peripheral neuropathy to initiate early treatment.5 The sooner the diagnosis is made, the greater the chances that the neuropathy can be arrested or even reversed. The three different types of symptoms are presented below in typical order of presentation and disease progression.
Sensory Symptoms. Sensory symptoms are extremely variable and can be divided into positive and negative symptoms.5 Examples of positive symptoms include different types of pain, such as burning, tingling, sharp, dull, and searing. There may be spontaneous sensations (paresthesias), unpleasant sensations (dysesthesias), or hypersensitivity (hyperalgesia) to pressure or touch. They are inherently classified as new, abnormal, and sometimes painful sensations.
Negative sensations may occur as numbness, loss of balance, heaviness in the legs, stiffness, or feelings of something bunched up on the ball or sulcus of the foot. These are only a few examples of patient chief complaints. Further examination may reveal a wider stance or base of gait, an unsteady gait, or loss of balance, especially with the eyes closed. These findings are the result of a loss of normal sensations.5,6,7
Motor Symptoms. Motor neuropathy is manifested by weakness in the arms or legs; however, in the early stages, the weakness may be too mild to recognize. Some of the subtle symptoms include heaviness in the legs, difficulty standing from a seated position, having to pull on the rail while climbing stairs, or tripping over uneven flooring. Weakness gradually will become more obvious as the disease progresses. Muscle wasting can be seen in the feet with loss of the intrinsic muscles, which can lead to muscle imbalance in the toes causing gradual clawing of the toes and other deformities.6 Muscle wasting occurs because of impaired signals to distal musculature in the body, usually affecting the intrinsic foot muscles. Once the signals are impaired or lost, the muscles do not function and atrophy from disuse. As these intrinsic foot muscles lose function, the larger extrinsic leg muscles gain advantage and deform the foot in a variety of contracted positions. This muscle imbalance is called an intrinsic minus foot with many prominences that can lead to ulcerative lesions.8 (See Figure 1.)
Figure 1. Intrinsic Minus Foot |
|
Note deep channels between the metastarsals indicative of lumbrical muscle wasting from denervation. |
 |
|
Image courtesy of Kevin F. Sunshein, DPM. |
Autonomic Symptoms. Autonomic symptoms can affect the legs and feet in several ways. Autonomic nerves regulate skin temperature and sweating. Patients with neuropathy, especially diabetic neuropathy, have challenges with atrophy, dry or overly moist skin, and hair loss on the legs. Autonomic neuropathy contributes to delayed skin healing and can affect the nails, which usually present as ridged, brittle, and/or dystrophic.2,6,9 The autonomic nervous system affects temperature regulation. When temperature is no longer regulated appropriately, patients can have abnormal signal proliferation, which manifests as sweating to the distal extremities. As the neuropathy progresses, temperature regulation limits itself and the skin becomes dry. Both environment types invite fungal proliferation due to the abnormal temperature conditions.
Evaluation and Diagnosis of Diabetic Peripheral Neuropathy
Often, evaluating peripheral neuropathy in patients with diabetes is secondary to the patients’ presenting chief complaint when seeing a podiatrist, as many patients are unaware of symptoms of neuropathy.10,11 Most commonly, patients initially present with foot problems such as ingrown, fungal, or deformed toenails; calluses; or wounds of the feet. A thorough review of systems will indicate the presence of diabetic neuropathy if particular attention is made to the neurologic system. Sometimes, patients have difficulty articulating exact symptoms of neuropathy since the progression of the disease can be insidious. Obvious symptoms may include numbness or painful tingling sensations in their feet, although early nerve damage to the feet may be indicated by changes not noticeable as concrete symptoms to the patient. Patients may make statements such as “my socks seem to be bunched up but when I take my shoes off to look, there is nothing wrong.”5 Many patients realize tingling and burning symptoms to their feet during the evening, although symptoms can be present all day.2,7,12
The most important aspect of the diagnostic evaluation is a complete and thorough history and physical examination. This should include whether the patient has type 1 or 2 diabetes mellitus, as well as the duration of the disease, management of the blood sugar, and any other systemic complications of diabetes, such as retinopathy or nephropathy. Routine blood work should include a complete blood count (CBC), hemoglobin A1c, complete chemistry profile, serum vitamin B12 levels, and renal and hepatic function tests.
The Diabetic Foot Exam
A typical foot exam is divided into four systems. Inspection of the skin will provide clues as to the health of the patient’s feet. Toenails that are abnormally thickened, opaque, crumbling, yellow in color, and malodorous are likely to be fungal, showing symptoms of sensory neuropathy, autonomic neuropathy, or both. Dryness of the skin is very common, but any signs of inflammation, especially along the plantar aspect of the feet or the medial and lateral borders, may indicate a chronic asymptomatic tinea pedis infection. The incidence of dermal fungal infections is much higher in the diabetic population because of a compromised immune system and is a clue to the patient’s overall health.2,7
Dermatologic Exam. The dermatologic exam of the foot and legs includes observation of any thickening or discoloration of the toenails and hyperkeratoses on the toes or balls of the feet. One telltale sign of neuropathy is subdermal hemorrhages within calluses.2 Most likely, all patients with full sensation to their feet would not be able to tolerate the pain that is associated with having enough pressure on the foot to produce subdermal hemorrhages within calluses. Peripheral neuropathy dulls sensation and allows patients to tolerate more prolonged pressure without pain on a small area of skin. Shear forces will cause the skin to react to abnormal stimuli and increase keratinization. Peripheral neuropathy may contribute to a patient wearing a smaller shoe than normal due to loss of sensation and the inability to feel rubbing and discomfort. In addition, any burns to the feet should be noted, as patients have temperature sensation loss and may unknowingly scald or burn themselves; this is more common in the winter.2
Autonomic neuropathy impedes regular skin moisture balance and regulation. Either the skin becomes too dry and scaly or it is too moist, which fosters dermatophyte infections and skin maceration within the webspaces. Often, dermatophyte infections may give the appearance of “dry skin,” further confusing a clinician. Differentiation includes inspection of the skin to evaluate for a chronic inflamed appearance, especially along the plantar and borders of the feet. This is referred to as moccasin dermatophytosis or dry tinea pedis.11,14
Vascular Exam. The vascular examination should include palpation of the dorsalis pedis and posterior tibial, and sometimes the perforating peroneal arteries. A dorsalis pedis artery is absent in approximately 2% of the population, and if a good strong pulse to the posterior tibial artery is present, it is acceptable to measure the perforating peroneal artery to ensure appropriate flow to the dorsal aspect of the foot.13 This will give the clinician a general overview of the macro-circulation. Capillary refill time to each digit is also important in determining blood flow to the toes and tests the microvasculature. The capillary refill time test is performed with the feet slightly above the level of the heart. Normal values are less than five seconds. Presence of peripheral edema may indicate autonomic neuropathy. Venous insufficiency should be noted if present; it manifests as pitting edema to the lower extremities, and sometimes brawny, brown discoloration to the lower legs up to the level of the mid-tibia.
Neurologic Exam. The neurologic exam includes evaluating the deep tendon reflexes. Examine both the patellar and Achilles reflexes. Loss of the Achilles reflex is indicative of advanced peripheral neuropathy. Sensation is tested for vibratory loss with a 128 Hz tuning fork. Decreased proprioception and loss of light touch indicate neuropathy. A Semmes-Weinstein 10 gm monofilament is used to test light touch in 10 places on each foot. Additional tests may include differentiating temperature gradients. Gait analysis will demonstrate balance deficiencies. Walking heel to toe may be quite difficult with peripheral neuropathy. A patient’s wider base of gait may indicate loss of proprioception, and balance may be significantly decreased with the eyes closed. The Romberg test (loss of balance with feet together and eyes closed) also is useful when evaluating for neuropathy.10
Musculoskeletal Exam. The musculoskeletal exam includes observation for any typical foot deformities, such as bunion (hallux valgus) deformities, contracted toes, and Tailor’s bunions (lateral exostosis fifth metatarsal head). Clinicians should look for any obvious asymmetric changes in arch height with the patient standing. Charcot deformities are quite obvious, but even subtle changes in the arch height may be a sign of more serious foot problems. The common complaints of a patient’s foot “looking funny” or changing in appearance and becoming red, hot, and swollen without any history of trauma to the area should at least warrant a radiograph and referral to a podiatrist for a thorough and extensive workup. Active Charcot changes in the feet are identified by unexplained swelling, particularly if only one foot is involved. Increased temperature changes with edema can be quite concerning and complete workup is required to “arrest” the development of breakdown of the arch with subsequent deformity, such as a rocker bottom type of foot. Differentials to a Charcot deformity include a diabetic foot infection, osteomyelitis and cellulitis, acute inflammatory arthropathy, gout, acute thrombosis, and trauma.15
Diagnostic Testing for Diabetic Neuropathy
The standard test to confirm peripheral neuropathy is the nerve conduction velocity (NCV) exam and the electromyograph (EMG) studies, although no gold standard has been established. These tests are fraught with problems when applied to the lower extremity because of the large number of variations in foot type.16 These tests examine how the nerves conduct electrical stimuli and the effects of the nerves on the muscles they supply. However, these tests only examine the large myelinated nerves. Electrodiagnostic exams provide little information concerning the function of the small unmyelinated axons. In a mixed large-fiber and small-fiber neuropathy, the NCV-EMG studies may be positive but would not give an adequate picture of the health of the small nerve fibers. These tests should be ordered either to confirm the findings from the neurologic evaluation or to obtain baseline information. Electrodiagnostic studies often can differentiate other causes of the neurologic symptoms, such as a spinal nerve root impingement. Patients should be referred first to either neurology or podiatry, as complete clinical exams may give more information.
An epidermal nerve fiber density biopsy is performed to evaluate the small unmyelinated nerve fibers, and is less painful than the above-mentioned tests. Podiatrists or neurologists are adept at performing this type of biopsy. This skin biopsy, usually performed on the lateral thigh or calf area, will give the practitioner an idea as to the severity of the small nerve fiber neuropathy. The decreased density of the dermal nerve fibers indicating a sensory neuropathy will be evident before changes are seen in the electrodiagnostic studies. Bilateral biopsies may indicate that the nerve density is not symmetrical.17
Treatment of Painful Diabetic Peripheral Neuropathy
Treatment of the painful symptoms from diabetic peripheral neuropathy requires a multifaceted approach in most patients. There is no one specific therapy that will prove beneficial to all patients. Many times, the side effects from the medications used to treat diabetic peripheral neuropathy will be more difficult to manage. Although the pharmacologic and alternative treatments are designed to reduce the painful effects of diabetic peripheral neuropathy, it is the loss of sensation and proprioception that place diabetic patients at extreme risk for loss of limb and or life.
Pharmacologic Treatment of Diabetic Peripheral Neuropathy. Treatment of symptomatic diabetic neuropathy addresses the painful component of this disease. Other than vitamin therapy, no drugs on the market today are available to reverse the neuropathy.18 Drug therapy has been the mainstay of treatment for painful symptoms. Since no single drug is available to treat pain caused by diabetic peripheral neuropathy, patients may require trials of different medications, both topical and oral, to treat their neuropathy symptoms completely and adequately. There is considerable variance between patients in their response to the therapeutic effect of any particular drug. In addition, side effects from taking these medications may negate the potential benefits.18
There are several classifications of pharmacologic agents used for painful sensory peripheral neuropathy, regardless of the cause. These include antidepressants, anticonvulsants, opioids, and topical agents. The anti-pain effects of anticonvulsants or antidepressants can occur over a wider range of doses than when used for other indications. The lowest therapeutic dose of any particular drug used to relieve the pain may be quite high and may cause side effects. Careful titration of the dose is needed to monitor the side effects of these drugs.
Neuropathy Pain Management with Anticonvulsant Drugs. Pregabalin (LyricaTM) is FDA-approved for painful diabetic peripheral neuropathy. Typical dosage for neuropathic pain starts at 150 mg/day. Start the dose in the evening so any side effects, such as drowsiness, do not interfere with the patient’s daily activities. Increase the dose up to a maximum of 300 mg daily. Potential side effects may include sleepiness, dizziness, difficulty concentrating, peripheral edema, and blurred vision.
Gabapentin (NeurontinTM). Start at 300 mg/day and increase by 300 mg every 5-7 days. Relief of diabetic nerve pain may require up to 2,700 mg/day or higher, taken in three divided doses. Common side effects include dizziness, fatigue, drowsiness, ataxia, and peripheral edema. Although gabapentin has the most evidence for treatment of painful neuropathy, it is not FDA-approved to specifically treat diabetic peripheral neuropathy.19
Neuropathy Pain Management with Antidepressant Drugs. Duloxetine (CymbaltaTM) is FDA-approved. Duloxetine is a selective neurotransmitter reuptake inhibitor for serotonin, norepinephrine, and, to a lesser degree, dopamine. The usual dosage is 30 mg/day and can increase by 30 mg every four days up to 60 mg twice daily. Side effects include nausea, dizziness, fatigue, dry mouth, constipation, loss of appetite, excessive perspiration, insomnia, and sexual dysfunction.
Amitriptyline (ElavilTM). Amitriptyline is a tricyclic antidepressant that affects the balance of neurotransmitters, such as serotonin. The usual dose is 25 mg at bedtime, with a maximum dosage of 150 mg daily in three divided doses. Side effects include drowsiness, dry mouth, urinary retention, and arrhythmia.20
Narcotic Management of Chronic Neuropathic Pain. Opioid analgesics and tramadol (UltramTM) generally are used as second-line treatment for severe pain from diabetic neuropathy. Narcotics should be used judiciously and treatment should be individualized for the patient, considering side effects vs. potential benefits and whether prompt onset of pain relief is necessary. Longer-acting opioids, such as oxycodone, are recommended for better efficacy. A shorter-duration narcotic or tramadol is more appropriate if the pain is occasional, of limited duration during the day, or sporadic rather than chronic. Side effects include constipation, dizziness and drowsiness, nausea, vomiting, pruritus, memory loss, anorexia, sexual dysfunction, and urinary retention.
Topical Medications for Treatment of Painful Diabetic Peripheral Neuropathy. Common topical treatments for diabetic peripheral neuropathy include capsaicin (ZostrixTM) and lidocaine 5% patches (LidodermTM). Capsaicin stimulates the C fibers to release and deplete substance P. Lidocaine 5% dermal patches block neuronal sodium channels. These prescriptions are not FDA-approved for diabetic peripheral neuropathy but can be used in conjunction with oral medications or if patients cannot tolerate them.
Compounded prescription topical formulations have evolved in the treatment of painful diabetic peripheral neuropathy. In a study by Somberg et al, combination creams consisting of ketamine (10%), baclofen (2%), gabapentin (6%), amitriptyline (4%), bupivacaine (2%), and clonidine (0.2%), as well as another cream with the same ingredients plus the addition of nifedipine (2%), were studied.21 Excellent or good effects were reported in 82% in the first group and 70% in the second group.22
While topical medications are not front-line therapies, they add one more tool in the treatment armamentarium for symptomatic painful diabetic peripheral neuropathy. Not all pharmacies perform compounding services, but there are many specialty compounding pharmacies in the marketplace.
Nutritional and Vitamin Therapy for Diabetic Peripheral Neuropathy. Chronic metformin usage results in vitamin B12 deficiency in 30% of patients.23 This can cause peripheral neuropathy. Supplementation with vitamin B12 has been shown to decrease symptomatic diabetic peripheral neuropathy.23
Alpha lipoic acid (ALA) also is known to have beneficial effects on diabetic polyneuropathy, although the exact mechanism by which ALA exerts its effect is unknown.24 ALA might exert its beneficial effects at least partially by improving microcirculation to the nerves.
Non-Pharmacologic Treatment Modalities for Painful Diabetic Peripheral Neuropathy. Non-traditional treatments for painful diabetic peripheral neuropathy are emerging and may bring symptomatic relief to those suffering from the debilitating effects of diabetic nerve damage. Many patients either do not tolerate medical therapies alone or do not have symptomatic relief from pain. There are technologies used that have been anecdotal in relieving symptoms. Multiple studies are looking at the effectiveness of such treatments. Alternative treatments, such as anodyne monochromatic infrared photo energy, transcutaneous electric nerve stimulation, frequency modulated electromagnetic neural stimulation, magnetic field treatment, and low light laser therapies, all have been used for symptomatic diabetic peripheral neuropathy.25 Frequency-modulated electromagnetic neural stimulation shows significant reduction in both nighttime and daytime pain.25 Although symptoms in this study returned three months post-treatment, intermittent therapy with this modality may provide relief of pain without the side effects of traditional pharmacologic agents.25
Foot Complications Due to Neuropathy
Loss of protective sensation will lead to severe and dire consequences for the patient with diabetes. Significant resources are used in the treatment of the complications of diabetic foot problems. Expenses from hospitalization, surgery, medications, chronic wound care, and loss of income represent significant burdens on the U.S. economy.4 According to the Centers for Disease Control and Prevention, the number of people in the United States with diabetes mellitus reached 27 million in 2007, with another 86 million people estimated to have prediabetes.4 The actual national cost burden of diabetes is estimated to exceed $174 billion, including the social cost of intangibles such as pain and suffering, care provided by nonpaid caregivers, medical costs associated with undiagnosed diabetes, and diabetes attributed costs.1 On average, medical expenditures are thought to be 2.3 times higher in people with diabetes compared to those without diabetes. Many of these expenditures likely are related to comorbidities associated with diabetes, including diabetic foot ulcers and lower extremity amputation.
Diabetic Foot Ulcers . Diabetic foot ulcers begin with the inability to feel normal sensations, such as pressure and pain. Loss of protective sensation leads to increased damage to the skin due to prolonged pressure that does not result in the normal response to a painful stimulus. When there are areas of callused skin caused by either foot deformities or excessive shear pressure (i.e., blister formation), ischemic changes from initial skin damage lead to further insult, resulting in erosion of the epidermis and dermis. Continued unabated, abnormal pressure may lead to fat necrosis and exposure of bone. The subsequent damage is noticed by patients not from pain but from either bloody discharge on their socks or from malodor that represents an infection.
Diabetic foot ulcers precede more than 80% of non-traumatic lower limb amputations.26 The most common sites for foot ulcers are toes, followed by the plantar metatarsal heads and the heel. Foot risk factors include peripheral neuropathy, peripheral arterial disease, and foot deformities.
Initial treatment begins with radiographic evaluation looking for any lytic bone margins, and assesses for underlying deformity that may be causing the diabetic ulceration. Lytic bone is indicative of osteomyelitis, which can be an effect of chronic ulceration. Once osteomyelitis and limb deformity are ruled out, conservative treatment with wound care is implemented. Necrotic skin, if present, needs to be debrided thoroughly to properly evaluate the depth of the ulcer and to remove any skin or soft tissue that may impede the healing process. If a patient’s ulceration is more severe with suspicion of osteomyelitis or clear underlying deformity, surgery may be necessary.
The extremity must be offloaded of all abnormal forces acting along the plantar aspect of the foot. This is the most difficult aspect to control. A diabetic foot ulcer on the plantar aspect of the foot must be relieved of the body weight to allow granulation of the wound to begin. Excessive shear pressures on the foot continue the destructive forces and will lead to further damage and increase the depth of the wound. It is imperative to stop the insult so the wound does not extend to bone.19,27,28 The gold standard for offloading diabetic foot ulcers is a total contact cast, although many patients cannot tolerate this.
Documentation of diabetic foot ulcers is important in assessing healing or healing potential. On initial presentation, note the appearance of the ulcer and surrounding area. Are the margins erythematous? Is there edema or erythema spreading away from the ulcer? Is there maceration, callused skin, malodor, tunneling, and drainage, and if so, is it mild, moderate, or severe? Measure the ulcer in length, width, and depth. Is there a granular base to the ulcer or is there fibrosis and necrosis of the wound? Note the depth of the wound. Is it partial or full thickness? Is it through the dermis into the fat or subcutaneous layer? Is tendon or bone exposed? Any exposure down to bone is ominous for osteomyelitis and mandates further investigation with magnetic resonance imaging (MRI), computed tomography (CT) scans, and appropriate blood work consisting of CBC with differential, erythrocyte sedimentation rate (ESR), C-reactive protein (CRP), and complete chemistry profile. An MRI typically is ordered if tendon or bone is exposed, but a bone scan or CT can be done if the patient has contraindications. There is a difference between an infected ulcer and a contaminated ulcer. Initial cultures and sensitivities may show colonization of multiple bacteria but not all of the bacteria are causing the infection if present. Gram-positive cocci are most common, although a wide variety of pathogens have been known to infect diabetic foot ulcers. The typical presentation of an infected ulcer includes erythema, edema, malodor, rubor, calor, and purulent drainage. Colonizers do not exhibit symptoms of infection. In the absence of infection, thorough debridement of the ulcer with removal of the perimeter callus and removal of any “high point” along the periphery of the ulcer will prevent undo pressure over the ulcer. Offloading of the ulcer is mandatory and the patient must be taken out of normal foot gear for the side affected.2,29 Appropriate offloading devices may include a stiff surgical shoe, although this is only slightly better than conventional shoes.29
Various devices to offload the foot include diabetic walking boots that are designed to keep the foot from bending, thereby reducing shear forces on the plantar aspect of the foot. In addition, a soft multi-density insole fitted into the boot can assist in offloading the foot.
The gold standard for offloading the foot in the management of diabetic foot ulcers is a total contact cast.29 Total contact casting has been used extensively to heal these difficult wounds. The practicality of using this type of cast has improved significantly in recent years with the development of several brands of fiberglass casting systems with improved ease of use. However, this type of casting technique requires expertise and diligence or it may cause further wound complications.28,30 The success of the total contact cast will depend on the expertise of the practitioner applying it and the patient’s cooperation. The cast needs to be changed at least weekly or sooner depending on the clinical necessity. The wound will need to be debrided as appropriate and measurements taken to document progress. Diabetic foot ulcers have many factors and are complex problems, so no definitive healing guidelines have been set; however, 50% improvement in one month is considered optimal.30
Once the wound is healed, measures must be taken to modify the patient’s foot gear to continue to address plantar shear forces acting on the foot. There are many types of shoes and shoe modifications that are available to achieve this. Adding custom molded foot orthoses to the shoes will help alleviate pressure off the plantar foot surfaces. It is much easier to prevent formation of plantar foot ulcers than to heal them. Many diabetic foot ulcerations are preventable, but it takes an extreme amount of diligence to educate and counsel patients on the significance that foot gear has on their feet. Custom foot orthotics are indicated and can be ordered by referring a patient to a podiatrist or directly through an orthotist. The authors recommend patients be established with a podiatrist, so all biomechanical and foot deformity accommodations can be prescribed.
Classification Systems of Diabetic Foot Ulcers. There are many wound classification systems used to describe diabetic foot ulcers. Two of the most well established systems used today are the Wagner system and the University of Texas San Antonio Diabetic Wound Classification System. (See Tables 4 and 5 and Figure 2.)
Table 4. Wagner Classification |
|
|
Grade |
Lesion |
|
0 |
No open lesions; may have deformity or cellulitis |
|
1 |
Superficial diabetic ulcer (partial or full thickness) |
|
2 |
Ulcer extension to ligament, tendon, joint capsule, or deep fascia without abscess or osteomyelitis |
|
3 |
Deep ulcer with abscess, osteomyelitis, or joint sepsis |
|
4 |
Gangrene of toes or forefoot |
|
5 |
Extensive gangrene of foot |
Table 5. University of Texas Diabetic Wound Classification |
||||
|
Grade 0 |
Grade 1 |
Grade 2 |
Grade 3 |
|
|
Stage A |
Pre-ulcer, no skin break |
Superficial wound, no penetration |
Wound penetrating tendon or capsule |
Wound penetration bone or joint |
|
Stage B |
With infection |
With infection |
With infection |
With infection |
|
Stage C |
With ischemia |
With ischemia |
With ischemia |
With ischemia |
|
Stage D |
With infection and ischemia |
With infection and ischemia |
With infection and ischemia |
With infection and ischemia |
Figure 2. Wagner Classification |
|
 |
 |
|
Grade 0 |
Grade 1 |
 |
 |
|
Grade 2 (Visible tendon) |
Grade 3 (Destruction on X-ray consistent with osteomyelitis) |
|
Images courtesy of Kevin F. Sunshein, DPM. |
|
The Wagner system is based mainly on wound depth and consists of six wound grades. These include grade 0 (intact skin), grade 1 (superficial ulcer), grade 2 (deep ulcer to tendon, bone, or joint), grade 3 (deep ulcer with abscess or osteomyelitis), grade 4 (forefoot gangrene), and grade 5 (whole foot gangrene). Infection is only included in one of the ulcer grades. It does not adequately address vascular components in most of the grades. Also, this system does not allow for classification of superficial wounds that are infected or dysvascular.5
First described in 1996, the University of Texas San Antonio Diabetic Wound Classification System addresses not only the depth of the wound but also the presence of infection or ischemia. This system is comprised of four grades based on depth with four subsections for each grade that address the vascular component and the presence or absence of infection.2
Infection
Infection of the diabetic foot ranges from superficial skin infections, localized cellulitis, infected ulcers, abscesses, osteomyelitis, septic arthritis, and necrotizing fasciitis. The sensory, motor, and autonomic neuropathy, in conjunction with factors such as deformities of the feet, compromised soft tissues and foot type, makes the contiguous spread of infection more likely than hematogenous etiologies.2 Many times, the presenting problem, such as an infected ingrown toenail or a small blister, may seem very minor. Sensory neuropathy leads to delay in treatment because of lack of feeling. Prolonged pressure on areas of the foot susceptible to trauma will lead to more dermal damage, and a bloody sock or foul odor may be the first indications to the patient that there is a problem.
Initial presentation of a hot swollen foot must be differentiated between an infection and neuroarthropathy. Obvious sources of infection, such as a blister, ingrown toenail, or foot ulcer, suggest infection over neuroarthropathy. A keen index of suspicion and a thorough history and physical examination are critical in the initial evaluation. Routine laboratory exams such as CBC with differential, ESR, CRP, basic electrolytes, renal function, and blood glucose should be ordered. Inflammatory markers may not be useful in deciding if there is an infection because patients with diabetes may not be able to mount a normal inflammatory response.15 However, an ESR of > 70 does suggest infection.27,31
Treatment of diabetic foot infections is guided by the severity of the infection. Non-limb-threatening infections involve superficial ulcerations without significant ischemia, and they do not involve bone or joint. Many diabetic foot infections may be treated on an outpatient basis with oral antibiotics in the absence of systemic manifestation, such as fever, chills, and malaise. Many mild or moderate infections are monomicrobial, with Staphylococcus aureus, Staphylococcus epidermidis, and streptococci the most common pathogens.32 Reliable specimens for cultures may be obtained through curettage of the infected ulcer. In addition to the standard treatment for ulcerations (i.e., offloading and dressing changes), oral antibiotic therapy usually is sufficient as initial therapy. Antimicrobial treatment should be started with an agent providing adequate Gram-positive coverage, recognizing that Gram-negative organisms also might be involved.
Hospitalization with intravenous antibiotic therapy is necessary for any severe foot infection. Localized pedal edema with erythema and ascending cellulitis and lymphangitis with or without ulceration require hospitalization whether there are systemic symptoms of infection. This type of infection requires a multidisciplinary approach to treatment, including consultations with internal medicine, infectious diseases, podiatry or orthopedics, vascular surgery, wound care, nutrition services, and social work.
Abscesses need to be drained in the operating room and may require further surgery. Partial toe or foot (transmetatarsal) amputations may be necessary. If the foot cannot be salvaged, a higher amputation, such as a Syme’s or below-the-knee amputation, may be required to stop the infection.13
Imaging
Plain radiography is imperative for assessment of the diabetic foot. It is inexpensive and readily available. Weight-bearing views should be taken if possible. Radiographs can detect osteomyelitis, osteolysis, fractures, dislocations seen in neuropathic arthropathy, medial arterial calcification, soft tissue gas, and foreign bodies, as well as structural foot deformities and the presence of arthritis.
The first sign of osteomyelitis is focal demineralization and may reveal soft tissue swelling.15 Periosteal reaction and osteolysis may be present but may not be definitive in reaching a diagnosis of osteomyelitis. The sensitivity of plain radiography is relatively poor, with a range of between 40-75%.15 Specificity is better, ranging from 60-90%. These numbers represent the delay of 10-20 days before signs of osteomyelitis are visible. The initial presentation of focal demineralization also is seen in neuroarthropathy and, therefore, may be indicative of either infection or neuroarthropathy.
Bone scans are an important tool in the management of diabetic foot infections, especially if the X-rays show non-specific bony changes. Often, it is very difficult to differentiate between the two without more advanced imaging techniques.
Technetium-99 methylene diphosphonate (Tc-99 MDP) bone scans often are used in diabetic foot infection to determine the presence of osteomyelitis. Although highly sensitive, this modality lacks specificity in the neuropathic foot.33 Osteomyelitis, fractures, arthritis, and neuropathic arthropathy all will demonstrate increased radiotracer uptake. However, a negative bone scan is strong evidence against the presence of infection. To improve the specificity of nuclear imaging, white blood cells can be labeled with Tc-99 hexamethyl propylene amine oxime (Tc-99 HMPAO), indium-111 oxime, or gallium-67 citrate. Indium-111 selectively labels polymorphonuclear leukocytes and is more specific for acute infections than Tc-99 MDP scanning. Chronic infections and inflammation are not well imaged with indium-111 because chronic inflammatory cells (i.e., lymphocytes) predominate and are not well labeled with indium. Combining Tc-99 MDP and indium-111 increases the specificity of diagnosing osteomyelitis.33
CT scans may be indicated in the assessment of suspected bone and joint pathology not evident on plain radiographs. CT offers high anatomic detail and resolution of bone with osseous fragmentation and joint subluxation. Subluxation of the transverse tarsal or tarsometatarsal joints can be seen prior to being visualized on radiographs.2,27,29
MRI usually is preferred over CT for the investigation of osteomyelitis, because of its enhanced resolution and ability to visualize the extent of any infectious process.27,29 MRI often is used in evaluating both soft tissue and bone pathology. This scan may be indicated to aid in the diagnosis of osteomyelitis, deep abscess, septic joint, and tendon rupture. It is a readily available modality that has a very high sensitivity for bone infection and also can be used for surgical planning.33
Vascular Evaluation in Diabetic Feet
The lower extremity should be assessed for vascular and neuropathic risk factors. Although positive findings in the neurologic examination rarely require further evaluation, positive findings of vascular insufficiency may require further consultation, as wounds may not heal without appropriate blood flow. Patients who have absent pulses, ulcers that do not exhibit healing through wound measurements, history of smoking, or kidney issues are at risk for vascular problems, along with patients who exhibit cramping in legs while walking certain distances or experience rest pain.
Noninvasive arterial studies should be performed to determine lower extremity perfusion. Such studies may include Doppler segmental arterial pressures and waveform analysis, ankle-brachial indices (ABI), toe blood pressures, and transcutaneous oxygen tension (TcPO2). Ankle-brachial indices may be misleading, because ankle pressures can be falsely elevated because of medial arterial calcinosis and noncompressibility of affected arteries.2,13 The indications for a vascular surgery consultation include an ankle brachial index of < 0.7, toe blood pressures < 40 mmHg, or TcPO2 levels < 30 mmHg, since these measures of arterial perfusion are associated with impaired wound healing.34
Charcot Neuroarthropathy
Charcot neuroarthropathy is a serious complication of diabetes characterized by joint dislocation, pathologic fractures, and severe destruction of the osseous architecture of the foot and ankle. This condition can result in debilitating deformity or even amputation. The etiology of Charcot neuroarthropathy most likely is a combination of the effects involved in the neurovascular and neurotraumatic theories.2 Trauma superimposed on a severely neuropathic extremity is the most widely accepted theory regarding the development of an acute Charcot foot. As a result of associated autonomic neuropathy, blood flow to the foot increases, resulting in osteopenia and attendant weakness of the bone.2 Because of the loss of protective sensation that accompanies peripheral sensory neuropathy, the patient is unaware of the initiating trauma and the profound osseous destruction that often occurs during ambulation. A vicious cycle ensues in which the patient continues to walk on the injured foot, allowing further damage to occur. The destruction commonly occurs in the midtarsal region of the foot causing a collapse of the medial longitudinal arch with abduction of the forefoot. The resultant deformity causes a rocker bottom appearance of the foot. Abnormal pressures along the plantar medial aspect of the foot more than likely will result in ulcerations and may progress to developing osteomyelitis due to deepening of the ulceration down to bone or joint structures.35
Early recognition and treatment is imperative to prevent collapse of the medial arch. In the initial stages of Charcot neuroarthropathy, the foot must be immobilized to reduce further trauma to the foot. Offloading (sometimes in the form of external fixation) the foot in the acute active stage of the Charcot foot is the most important management strategy that can arrest the progression to deformity.2 Initial imaging options are plain radiographs, MRI evaluation, and conventional three-phase bone scan (technetium-99m MDP). If plain radiographs are negative, either the MRI or bone scan can confirm changes in the bony architecture or increased blood flow to the affected area.
Duration and aggressiveness of immobilization and offloading are guided by clinical assessment of healing of Charcot neuroarthropathy based on edema, erythema, and skin temperature changes.35 Serial X-rays and MRI are needed to help in the clinical decision to transition the patient into foot gear. Specialized custom braces, such as a Charcot restraint orthotic walker, may be needed long term to prevent foot deformity.
Guidelines for Proper Foot Health in Diabetic Patients
A healthy, intact diabetic foot is best maintained by a consistent and recurrent preventive treatment strategy as it is for diabetes in general. This is best accomplished through a multidisciplinary approach involving a team of specialists and personnel who provide a coordinated process of care. Team members may include a podiatrist, internist, ophthalmologist, endocrinologist, infectious disease specialist, cardiologist, nephrologist, vascular surgeon, orthopedic surgeon, nurse (educator, wound care, and home care), and pedorthist/orthotist. Patient and family education assumes a primary role in prevention. Such education encompasses instruction in glucose assessment, insulin and other diabetes medication administration, diet, daily foot inspection and care, proper footwear, and the necessity for prompt treatment of new lesions. Regularly scheduled podiatric visits, including debridement of calluses and toenails, are opportunities for frequent foot examination and patient education. Such visits can provide early warning of impending problems and subsequent modification of activity and care; they also can alleviate the catastrophic complications frequently associated with diabetic peripheral neuropathy.
Any patient who begins to exhibit foot deformity or symptoms of neuropathy should be referred to a podiatrist to establish baseline foot care and evaluation. These visits can prevent problems down the line and educate the patient about necessary foot care. The sooner the patient is evaluated, the more likely that severe foot complications will be avoided. However, prevention is the best treatment. Typically, patients with neuropathy should be seen by a podiatrist every six months, and sometimes sooner if they exhibit progression of their disease or have any severe foot deformity.
Summary
Many routine and common foot disorders may become limb threatening in the neuropathic diabetic foot. Loss of protective sensation and the presence of any foot deformity places the diabetic patient at great risk for foot ulceration with subsequent infection and possible loss of limb. This can be greatly minimized with routine foot evaluations. Prevention and appropriate patient education are critical in decreasing the morbidity and mortality effects from diabetic neuropathy.36
