AUTHORS
Whitney Minnock, MD, University of Arizona, Department of Emergency Medicine and Pediatrics, Tucson
Christopher Minnock, MD, University of Arizona, Department of Orthopedic Surgery, Tucson
Aaron N. Leetch, MD, Assistant Professor of Emergency Medicine & Pediatrics, Assistant Residency Director, EM and EM/Peds Programs, Banner University Medical Center, Tucson, AZ
PEER REVIEWER
Larry B. Mellick, MD, MS, FAAP, FACEP, Professor of Emergency Medicine, Professor of Pediatrics, Augusta University, Augusta, GA
To reveal any potential bias in this publication, and in accordance with Accreditation Council for Continuing Medical Education guidelines, we disclose that Dr. Dietrich (editor), Dr. Skrainka (CME question reviewer), Ms. Wurster (nurse planner), Dr. Whitney Minnock (author), Dr. Christopher Minnock (author), Dr. Mellick (peer reviewer), Ms. Coplin (executive editor) and Ms. Mark (executive editor) report no relationships with companies related to the field of study covered by this CME activity.
EXECUTIVE SUMMARY
- The most common diagnosis for atraumatic hip pain and limping is transient or toxic synovitis, which is diagnosed in as many as 85% of children presenting with this condition.
- Pain characteristics can help with the differential. Constant pain is more concerning for infection or malignancy. Morning pain is more consistent with inflammatory joint disorders. Pain after activity may indicate an overuse injury such as a stress fracture, osteochondritis dissecans, Sever’s syndrome, or Osgood-Schlatter disease. Night pain that wakes a child could indicate malignancy. Night pain relieved by nonsteroidal anti-inflammatory drugs (NSAIDs) is characteristic for osteoid osteoma, but not diagnostic.
- Transient synovitis is a self-limiting condition that is treated conservatively with rest and NSAIDs and typically resolves within 3-10 days.
- Because of the complications that can arise from prolonging appropriate treatment for septic arthritis, patients with an intermediate or high probability of septic arthritis should undergo an ultrasound or fluoroscopically guided hip aspiration. Positive cultures, a white blood cell count > 50,000 per mL in the synovial fluid, or a positive Gram stain confirm the diagnosis of bacterial septic arthritis.
- Patients with Legg-Calve-Perthes classically present with a limp, mild pain described as radiating to the groin and localizing to the hip join, and/or limited hip motion, and may present to the ED during any phase of the disease process.
- Slipped capital femoral epiphysis more commonly affects boys, with an average age of 13.5 years for males and 12 years for females. More than half of the patients affected are in the 95th percentile or higher for weight. Bilateral involvement occurs 18-50% of the time.
- Patients who are below the 10th percentile for weight or younger than 10 years of age should be worked up for metabolic causes, including hypothyroidism and osteodystrophy.
- Discoid meniscus is a diagnosis that includes a range of meniscal disorders affecting the shape and stability. On physical exam, a dramatic clunk may be appreciated with McMurray’s test due to subluxation of this abnormal meniscal tissue. This finding is present in approximately 40% of patients.
Definition of the Problem
The evaluation and management of a child with a limp and/or hip pain is a common issue for the emergency physician. The differential diagnosis is broad and includes disease of the spine, hip, leg, and even foot. These pathologies range from benign inflammatory conditions to more serious conditions, such as septic arthritis or even neoplastic processes. The conditions causing a limp may be chronic or acute. Some acute limp causes include traumatic injuries, foreign body in the foot, septic arthritis, transient synovitis, osteomyelitis, slipped capital femoral epiphysis (SCFE), and diskitis. Other more chronic or indolent causes of limp include rheumatic disease, Legg-Calve-Perthes disease, developmental dysplasia of the hip, neoplastic disease, and overuse injuries.1-3 It can be difficult to decide when to obtain laboratory tests and imaging on these patients, particularly nonverbal infants or young toddler-age children. The limp or painful hip may be an early sign of significant processes that could result in severe long-term complications if not diagnosed and treated in a timely fashion.4 Defining a systematic approach tailored for this can reduce time spent in the emergency department (ED) and ensure appropriate testing is performed to achieve the correct diagnosis.5 This review will focus mainly on the minor musculoskeletal trauma and atraumatic causes of limp and hip pain in the pediatric population.
Epidemiology
Limping and hip pain are familiar chief complaints to emergency physicians and may be atraumatic or traumatic in etiology. One institution noted that 5% of its ED visits were for inability to bear weight or because of a limp.2 Most of these presentations are secondary to traumatic injuries and will be self-evident.8 In contrast, atraumatic limp or hip pain can be variable in presentation and can pose a diagnostic dilemma for the emergency medicine practitioner. At one institution, it was found that over a six-month period, the incidence of atraumatic limp was 1.8 per 1,000, and the male to female ratio was 1.7:1, with a median age of 4.35 years.6 The most common diagnosis for atraumatic hip pain and limping is transient or toxic synovitis, which is diagnosed in as many as 85% of children presenting with this condition.2 Osteomyelitis and septic arthritis, whose complications include limb deformity secondary to growth arrest, joint stiffness, and osteonecrosis, fortunately are less common, but up to 50% of these occur simultaneously with both joint and bone involvement.4,7 Other causes include slipped capital femoral epiphysis, Legg-Calve-Perthes disease, developmental dysplasia of the hip, neoplastic disease, overuse injuries, toddler’s fracture, rheumatologic processes, and even blood dyscrasias. All of these must be considered when evaluating a pediatric patient with limp or hip discomfort.
Etiology
A child usually limps because he or she has pain in one or both legs or hips with walking. The pain may arise from the soft tissues, bone, joint, or be referred from elsewhere. The initial step in establishing a diagnosis is elucidating the exact location of pain. This may be easy in an older child who is able to verbalize and localize where the pain is, but is far more difficult in the toddler or infant. Thus, examination and history will be crucial to establishing the site of pain. Once this is known, the cause can be investigated further. The age of the child and the pattern of gait can further help guide the diagnosis.3 (See Table 1.)
Table 1. Differential Diagnosis of Antalgic Limp in Children by Age1,3 |
||
|
1-5 years |
5-12 years |
> 12 years |
|
|
|
When evaluating a child with a limp, it is imperative to identify the gait abnormality, determine the location of origin, and use this to develop a short differential list.3 This differential list is used to guide the workup, which includes starting with a thorough history and physical examination.
Clinical Assessment
History. A history often can be difficult to obtain from a young child or infant and requires input from parents if available. The initial focus of the history should include location of pain, duration of symptoms, traumatic injury, prior pain in the area, and other associated symptoms.11 If symptom onset is acute and severe, consider infection, trauma, and even malignancy. If gradual and chronic in onset, think about inflammatory or mechanical conditions. Constant pain is more concerning for infection or malignancy. Morning pain is more consistent with inflammatory joint disorders. Pain after activity may indicate an overuse injury such as a stress fracture, osteochondritis dissecans, Sever’s syndrome, or Osgood-Schlatter disease.3 Night pain that wakes a child could indicate malignancy. Night pain relieved by nonsteroidal anti-inflammatory drugs (NSAIDs) is characteristic for osteoid osteoma, but not diagnostic.
The location of the pain is important, but keep in mind that it could be referred from another location. This is particularly common in painful hip conditions that often refer to the knee. Buttock or lateral thigh pain may be referred from the back and spine. Pain that is located in more than one joint is more likely to be from an inflammatory cause.
History of recent viral upper respiratory tract infection is associated with transient synovitis. History of methicillin-resistant Staphylococcus aureus (MRSA) infections may be associated with septic arthritis or osteomyelitis. Tick bites could precipitate a Lyme arthropathy.
Failure to reach motor milestones could point to a neuromuscular disease process. Adolescent patients should be asked about sexual activity, as they may be at risk for gonococcal arthritis.
Evaluation of Gait Patterns. A limp is defined as a deviation from the normal pattern of gait. When evaluating a child with a limp, one must understand the normal walking patterns by age.2 Children typically begin to walk around 12-16 months of age. They tend to have a wide-based gait, short stride length, and fast cadence.2,13 The wide-based gait helps provide more stability as the children continue to develop balance with age. Toddlers tend to have frequent falls because of poor balance and immature motor skills, thus increasing the likelihood of traumatic injury. It is not uncommon for them to demonstrate foot slapping with walking.2 By age 3 years, children tend to walk with more symmetry, but still lack some balance and hip abductor strength to maintain a single leg stance for long. They also tend to have a short stride. By age 7 years, most children exhibit a normal adult gait pattern. Normal gait is smooth, rhythmic, and advances the center of gravity with the least expenditure of energy.2,3,12 The stance and swing phases are terms used to describe gait cycles.
Gait can be altered by pain, a mechanical problem, or a neuromuscular problem. Evaluating a limping child reveals specific patterns of deviation from normal gait. Antalgic gait is the result of pain in the affected limb. The child attempts to avoid pain in the affected limb by shortening the single-leg stance in this limb. Stride length is shortened on the opposite limb to limit the amount of time spent in single-leg stance phase on the painful limb. This allows the child to return to bearing weight on the non-painful extremity as quickly as possible.3,12
A few variations of antalgic gait can be seen in certain disorders. A child with back pain (i.e., diskitis) may lose the normal rhythmic flexion and extension of the lumbar spine. This can be elicited by having the child bend to pick up something off the floor. Another variant of antalgic gait is complete refusal to walk, most often seen in toddlers. This is seen when the patient cannot alter his or her gait to avoid the pain and, hence, completely refuses to walk. Children with a painful limb may ambulate with circumduction of their hips. This excessive hip abduction allows them to clear the foot without motion of the painful joint. This often is seen in pathology of the ankle.3
Nonantalgic gait disturbances also may be seen. (See Table 2.) Children with a short limb may vault off the short limb or toe-walk to clear the long leg. Equinus gait (toe walking) occurs when ankle dorsiflexion is limited and could be the result of a tight heel cord (gastroc-soleus spasticity or shortening of the Achilles tendon), limb-length discrepancy, clubfoot, or a neurologic disability such as cerebral palsy.2,3 Trendelenburg gait occurs with altered hip mechanics, particularly weakness of the hip abductors. The child will appear to be shifting his or her weight over the affected hip during stance phase. A variation of Trendelenburg gait is the waddling gait of a child with bilateral hip dislocations. Stance phase is not shortened, as it is in an antalgic gait, and this can help differentiate these two distinct gait patterns.2,3
Table 2. Differential Diagnosis of a Nonantalgic Limp |
|||
|
Trendelenburg Gait |
Circumduction Gait |
Steppage Gait |
Equinus Gait |
|
|
|
|
|
SOURCE: Author adapted. |
|||
Steppage gait occurs with weak ankle dorsiflexion. To compensate for ankle weakness, the child increases knee flexion in the swing phase to clear the foot. The foot may slap the ground because the ankle dorsiflexors are unable to decelerate the foot between heel strike and flat foot.
Evaluate the gait closely, look at symmetry of gait, abnormal limb rotation, balance, and upper extremity positioning during gait. Careful analysis of the gait pattern will help localize the origin of the limp and thus further guide the diagnostic workup.
Physical Exam. If possible, the child’s gait should be assessed first. It is important to have the child remove all or most of his/her clothing so that the extremities, skin, joints, and skin folds can be assessed thoroughly. Evaluate the patient’s gait closely, looking for limp and symmetry of gait, abnormal rotation, and overall balance.3,12 If the child is unable to walk, evaluate the extremities and spine while the child is sitting. Begin with the non-affected side (if the pain or disturbance is localized) and leave the affected limb until the end. Assess the skin for any rashes or skin lesions. These could provide clues to diagnosing Lyme disease, rheumatologic processes, foreign bodies, or traumatic injuries. Be sure to assess the spine and evaluate for tenderness or deformities. Abnormal findings could provide clues for the cause of limp such as trauma, osteomyelitis, or even diskitis. Evaluate the pelvis. Fully range all joints of the extremities. Palpate musculature for masses or areas of tenderness. Perform a full neurological assessment of the extremity for both motor and sensory nerves.2
The workup then should be guided by history and physical exam. There are many etiologies of hip pain and gait disturbance. These will be described in further detail with attention to the more serious, critical, and time-sensitive conditions.
Causes of Limp
Transient Synovitis and Septic Arthritis
Transient synovitis is defined as a benign inflammatory condition affecting the hip that is self-limited and is often diagnosed after other more serious conditions have been ruled out.15 It has been called several different names, including transitory coxitis, acute transient epiphysitis, coxitis fugax, coxitis serosa seu simplex, phantom hip disease, toxic synovitis, and observation hip.15 The literature describes an incidence of approximately 0.2%, most often in children between 3 and 8 years of age, and it is more common in males.15 Infrequently it will occur bilaterally. Most of the epidemiological data are from European countries and are extrapolated. The underlying etiology of transient synovitis is not definite, but there is some correlation with preceding viral symptoms, such as upper respiratory tract infection or vomiting and diarrhea.16 Older studies have demonstrated a correlation with minor trauma preceding the disease process.
The patient with transient synovitis usually will present with groin or thigh pain, a limp, and will not bear weight on the affected side. Often, the hip will be abducted and externally rotated at rest, and pain will be elicited during various movements, particularly passive range of motion.16 When the hip is flexed, abducted, and externally rotated, there will be lower intracapsular pressure and, thus, this position will be most comfortable for the patient.15 Transient synovitis is a self-limiting condition that is treated conservatively with rest and NSAIDs and typically resolves within 3-10 days.
Contrary to the relatively benign course of transient synovitis is that of septic arthritis. The diagnosis is made by clinical assessments and the use of laboratory and imaging studies to exclude other diagnoses. Several studies emphasize the variables used to differentiate transient synovitis from septic arthritis, as their presentations tend to be quite similar.17-20
One study developed an algorithm for predicting the probability of septic arthritis and included fever (temperature > 38.5° C), inability to bear weight, erythrocyte sedimentation rate (ESR) > 40 mm/hour, and serum white blood count (WBC) > 12.0 x 106 cells/L. In this group of patients, the probabilities of septic arthritis with one, two, three, and four predictors present were 3%, 40%, 93.1%, and 99.6%, respectively.17 (See Table 3.) When adding a C-reactive protein (CRP) > 1 mg/dL, the predicted probabilities of three, four, and five positive factors were found to be 83%, 93%, and 98%, respectively.20 Fever was found to be the most significant predictor, followed by increased CRP in one study.21 However, a CRP > 2 mg/dL was found to be the strongest independent predictor of septic arthritis.22
Table 3. Modified Kocher Criteria17 |
|
|
Parameter |
Threshold Value |
|
Temperature |
> 38.6° C |
|
White blood cell count |
> 12,000/mL |
|
Erythrocyte sedimentation rate |
> 40 mm/hr |
|
C-reactive protein |
> 20 mg/L (2 mg/dL) |
|
Functional status |
Unable to bear weight |
|
SOURCE: Author adapted. |
|
The workup should include plain radiographs, which occasionally show medial joint space widening in transient synovitis but are not considered sensitive for evaluating a joint effusion.23 More importantly, they can help rule out fracture, Legg-Calve-Perthes disease, and slipped capital femoral epiphysis. Ultrasound is noninvasive and can reliably detect a small hip effusion; however, it cannot distinguish between the causes of hip effusion.23,24,25 Lack of effusion can be helpful in excluding septic arthritis, but is not definitive, particularly in the early stages of the disease.25
Bone scintigraphy is useful in evaluating multifocal musculoskeletal infections, but is not sensitive nor specific to distinguish transient synovitis from septic arthritis.23,25
MRI is useful in determining if a patient has septic arthritis or transient synovitis, particularly with an equivocal clinical presentation and ultrasound results. MRI facilities are not always readily accessible and they often require administration of general anesthesia in the youngest pediatric patients.15
MRI findings of transient synovitis will reveal a joint effusion and absence of signal intensity abnormalities in the bone marrow. Findings supportive of septic arthritis rather than transient synovitis include decreased perfusion in the femoral head, signal intensity alterations, and contrast enhancement of the soft tissue and increased signal intensity in the bone marrow.26-28 (See Figures 1 and 2.)
Figure 1. Coronal T1 Fat Suppressed Gadolinium Enhanced Image |
|
Note the right femoral epiphysis is hypoenhancing |
Figure 2. Coronal STIR Image with Right Joint Effusion and Enhancement of Acetabulum |
 |
Because of the complications that can arise from delayed treatment for septic arthritis, patients with an intermediate or high probability of septic arthritis should undergo an ultrasound or fluoroscopically guided hip aspiration. Positive cultures, a WBC > 50,000 per mL in the synovial fluid, or a positive Gram stain confirm the diagnosis of bacterial septic arthritis.
Treatment for septic arthritis within 72 hours of symptom onset can reduce complications, such as sepsis, growth abnormalities, and loss of motor function.14 Surgical debridement and antibiotic therapy are the mainstays of therapy. Initial antibiotic choice should include broad coverage for MRSA.35 (See Table 4 for details.) Researchers have proposed that a short course of adjuvant dexamethasone can promote earlier improvement of both laboratory and clinical parameters as well.38
Table 4. Empiric Antibiotic Recommendations for Musculoskeletal Infections in Pediatrics7,35 |
||||
|
Age Group |
Antibiotic |
Dose (mg/kg) |
Route |
Frequency |
|
Neonates (< 1 month) |
Ampicillin/Sulbactam + Gentamicin |
150 2 |
IV IV |
q6h q8h (titrate after 3rd dose) |
|
Neonates (1-3 months) |
Vancomycin + Ceftriaxone |
15 100 |
IV IV |
q6h (initially) q24h |
|
Pediatrics and adolescents |
Clindamycin ± Vancomycin |
10 15 |
IV IV |
q6h q6h (initially) |
|
SOURCE: Author adapted. |
||||
Osteomyelitis
Pediatric bone and joint infections peak at a rate of 80 per 100,000.7 Osteomyelitis and soft tissue infections may present with limping and antalgic gait. These may be difficult to diagnose, and exam findings may not be obvious, particularly early in the disease course. Patients may present with a local cellulitis or induration of the extremity, point tenderness, or painful range of motion of the affected joint.
Initial workup should include an X-ray, although these may be falsely negative; it takes 7-10 days for the periosteal reaction along the infected bone to be evident. Lab markers, including WBC, ESR, and CRP, will be elevated in most cases. MRI with contrast is the study of choice for diagnosing these infections and other soft tissue infections. Treatment includes antibiotics with or without surgical debridement in extensive or non-responsive cases. Pathogens are similar to those for septic arthritis and occasionally these will occur together.2
Developmental Dysplasia of the Hip
Developmental dysplasia of the hip (DDH) is the most common defect in newborns, with an incidence ranging from 1-35 per 1,000 live births.9 The definition encompasses a spectrum of abnormal findings of the developing hip. These range from subtle findings on X-rays to subluxation and dislocation of the hip joint. It is suspected that some cases of DDH are a result of specific genetic polymorphisms, although they can be multifactorial. In the absence of family history, the risk of a child being born with DDH is 0.2%, whereas children with parents with DDH have a 12% risk, and siblings of those with DDH have a 6% risk. There is a female predominance of 8:1. The risk is increased in breech deliveries.8,9,10
Infants can be clinically evaluated using the Barlow and Ortolani tests. The Barlow test is done by pressing posteriorly on the flexed, adducted thigh. If the hip is dislocated at rest or with posterior stress, then the examiner should determine if the hip is reducible. This is the Ortolani maneuver, which is performed by moving the flexed hip into abduction while pressing the greater trochanter toward the acetabulum.9 Leg length discrepancy and a limp may be the presentation in children over 1 year of age. In infants younger than 6 months, ultrasound is the gold standard for diagnosis. In older children, X-rays are the used.
Orthopedic referral is indicated and treatment in infants usually encompasses the use of a Pavlik harness or, in refractory cases, splinting and casting. Rarely, patients will require surgical intervention by an orthopedist.9
DDH without dislocation can be clinically silent in children, and these patients may not develop symptoms until adolescence or adulthood. They often present with chronic hip pain and/or degenerative disease.10
Legg-Calve-Perthes Disease
Legg-Calve-Perthes disease has been perplexing orthopedists and physicians for more than 100 years and still has unknown etiology. It affects children most commonly between 4-8 years of age, but has been reported from 2 to 15 years of age. The incidence is approximately 1 in 1,200 children, with geographic variation. The male-to-female ratio is 5:1. It occurs bilaterally only 10-15% of the time.39
The pathophysiology is complex, but the key event is disruption of blood supply to the femoral head. There is a four-stage process to the disease, including the initial vascular insult, fragmentation of the bone, reossification, and healing/remodeling phases. Ischemia to the bone in the femoral head leads to necrosis. Many microfractures occur from normal daily wear and tear forces across the joint, but there are no viable bone cells to repair them secondary to the lack of blood flow. The microfractures accumulate. Then blood flow is reestablished to the area. The necrotic bone is resorbed, further weakening the mechanical strength of the femoral head by resorbing bone. Normal activities place a lot of load through the hip joint, eventually causing focal bone collapse and death of articular cartilage. This is called the fragmentation phase. It usually lasts one year. The next phase is the reossification phase, where the bone repairs the areas of bone necrosis and collapse with new bone. This process lasts three to five years.40 Femoral head deformity may worsen or improve during this phase. The degree of resultant deformity determines outcome of the disease, which is pain, hip function, and the early development of hip joint arthritis.
Patients classically present with a limp, mild pain, and/or limited hip motion and may present to the ED during any phase of the disease process. The onset is typically insidious. Pain usually is described as radiating to the groin and localizing to the hip joint. Occasionally, pain also radiates to the knee, like with other conditions affecting the hip. Pain often is worse with internal rotation and abduction. The effects on the hip joint are progressive over time and the disease severity varies. At first, hip motion will remain good, but the joint can have a synovitis and be irritable at times. This can produce a limp with an antalgic gait.
More severe disease can affect hip function and produce a Trendelenburg gait as the femoral head collapses and the abductor muscles are shortened and have less tension. On radiographs, variable amounts of femoral head collapse and deformity are seen. There may be no abnormal findings, especially early in the disease process. An MRI of the hip will show the areas of focal femoral head avascular necrosis.41
Key factors for long-term outcome are age at onset, how spherical the femoral head is, and how congruently the femoral head matches the acetabulum. Children with a disease onset at 6 years of age or younger tend to do well with nonoperative treatment. This includes observation and sometimes protected weight-bearing during the fragmentation phase. Children 8 years of age or older at onset fared better with outpatient operative procedures. These include osteotomies of both the femur and the acetabulum to improve the mechanics of the hip joint, with the goal to prevent or delay early onset of arthritis.
In diagnosing Legg-Calve-Perthes disease, other causes of osteonecrosis must be considered. These include sickle cell disease and corticosteroid therapy. These children are affected bilaterally though, whereas Legg-Calve-Perthes disease is usually unilateral. If Legg-Calve-Perthes disease is bilateral, then most often the disease process is in different stages on each side. The femoral head deformity will not look symmetric like it will with a systemic skeletal dysplasia.39
Slipped Capital Femoral Epiphysis
SCFE affects children later than Legg-Calve-Perthes disease. The average age for affected boys is 13.5 years old and for girls is 12 years old. These ages are decreasing over time because of the increase in childhood obesity. At least half of patients affected are in the 95th percentile or higher for weight. Bilateral involvement occurs 18-50% of the time.42 Patients who are below the 10th percentile for weight or younger than 10 years of age should be evaluated for metabolic causes. These metabolic causes that predispose patients include hypothyroidism and osteodystrophy.
Patients present with a pain in the groin, thigh, and sometimes the knee. They may or may not be able to walk. A limp will be present to varying degrees. The gait is antalgic in the early phase and becomes more of a Trendelenburg gait in chronic untreated cases. In severe cases, the child will not be able to bear weight. Hip motion is affected with internal rotation of the hip decreased.42
SCFE is defined as acute if symptoms have been present for less than three weeks, whereas chronic SCFE has symptoms present for more than three weeks. Acute-on-chronic SCFE also can occur when a patient has chronic symptoms (more than three weeks) but an acute exacerbation due to a more abrupt and pronounced slippage.43 A combination of biomechanical and biochemical factors contribute to a weakening of proximal femur epiphysis. Mechanical factors, such as obesity, increase force across the physis. It is hypothesized that rapid growth during puberty causes the physis to become even more susceptible to SCFE. The proximal femur metaphysis slips or shifts so that the femur moves anterior and superior relative to the femur epiphysis, which remains seated in the acetabulum. This has the effect of making the femoral head appear to have slipped posteriorly and inferiorly, although the femur moves relative to the femoral head. This displacement is most easily appreciated on the frog leg lateral X-ray view, but subtle SCFE can be seen on the anterior-posterior X-ray. Klein’s line is a line that runs along the anterosuperior femoral neck drawn on the anterior-posterior pelvis. (See Figure 3.) This line should intersect some portion of the epiphysis of the femoral head.44 In patients with SCFE, this line is flush or does not intersect the epiphysis. There is a variable amount of displacement seen with these slips.
Figure 3. Frontal View of 10-year-old Girl with Left SCFE |
|
Normal and abnormal Klein’s line highlighted
|
Clinical classification of SCFE defines stable and unstable slips. If a patient is able to bear any weight on the affected leg, even partial weight-bearing with crutches, then the slip is considered stable. Inability to bear any weight at all defines an unstable slip. This is important because the rate of future associated femoral head osteonecrosis is 50% if the slip is unstable and nearly 0% if it is stable.43 Regardless of whether the slip is stable, this is a surgical condition that needs treatment to prevent further displacement. Treatment consists of percutaneous screw fixation. If a patient has a metabolic condition that contributes to a SCFE (i.e., hypothyroidism, renal osteodystrophy) then the other side is often prophylactically surgically treated with in situ screw fixation.
Osteochondritis Dissecans
Osteochondritis dissecans is an acquired lesion in the knee in which the articular cartilage and bone develop cracks that cause locking, catching, and painful joints. It has a low incidence and commonly affects children 10-15 years of age. These lesions are divided between those that occur in skeletally immature patients with open physes (juvenile) and those that occur after skeletal maturity (adult form). This lesion occurs in the subchondral bone, with 70% of lesions located on the posterolateral aspect of the medial femoral condyle. The etiology of this process is unknown but can result in delamination and separation of the cartilage overlying the affected subchondral bone.46 It is hypothesized that repetitive microtrauma leads to this condition. Lesions are described as stable if they have secure attachment, and the cartilage has not displaced. Unstable lesions can become a loose body in the knee.
The clinical presentation is variable and depends on the size and stability of the lesion. Pain localizes to the knee. Stable lesions may have minimal symptoms. More severe or unstable lesions can cause patients to present with knee pain, often with an antalgic limp. If loose bodies are present, then the patient may experience locking or catching symptoms in the knee. The knee may have an effusion.
The workup should include knee radiographs. These will show a radiolucent lesion, again commonly on the medial femoral condyle. A notch view X-ray is the best view to visualize these lesions. MRI will characterize the lesion size, status of the subchondral bone, and presence of loose bodies, but this can be done in follow-up.
Treatment depends on the stability of the lesion. This is not an urgent condition, so patients seen in the ED should be given a knee immobilizer, remain non-weight-bearing, and follow up with an orthopedic surgeon. If the lesion is stable, conservative treatment is pursued with activity modification and/or weight-bearing restriction, temporary knee immobilizer use, and observation. For stable lesions, 50-75% will heal with nonoperative treatment.47 The presence of open physes (juvenile form) in general has a better prognosis than the adult form, regardless of stability. Unstable lesions and loose bodies often require surgery to address the cartilage lesion/defect and remove the loose body.47
Discoid Meniscus
Discoid meniscus is a diagnosis that includes a range of meniscal disorders affecting the shape and stability.49 These occur in approximately 3-5% of the U.S. population.50 The true incidence is unknown, as many people likely have mild variants and no symptoms. It most often affects the lateral meniscus. The morphology varies, but the discoid meniscus occupies more space in the lateral knee than a normally developed meniscus. The structure is often block shaped as opposed to the crescent shape of a normally developed meniscus.49,51 These discoid menisci can be stable or unstable. Children commonly present with a palpable and often audible snapping of the knee when the knee moves from flexion to extension.49 In young children (3-4 years of age), this snapping is often asymptomatic. Older children (8-10 years of age) can experience pain with activity. On physical exam, a dramatic clunk may be appreciated with McMurray’s test due to subluxation of this abnormal meniscal tissue. This finding is present in approximately 40% of patients.57
Patients will present to the ED with knee pain and symptoms of popping and clicking in the knee. Radiographs are often normal in patients with discoid menisci. In severe cases, squaring of the lateral femoral condyle or widening of the lateral joint line can be seen. MRI shows the anatomy of the meniscus and the evidence of tearing, if present, but again this can be obtained in follow-up. Discoid meniscal tissue is abnormal and more friable. In combination with the increased size of the meniscus, this leads to meniscal tears. Traumatic meniscal tears in children older than 10 years of age usually occur in the setting of discoid meniscus.48 With meniscus tears, there can be a knee effusion, locking, catching, or popping in the knee. If the patient has a meniscus tear or a painful discoid meniscus, treatment should include a knee immobilizer, protected weight-bearing, and referral to an orthopedic surgeon. Stable discoid menisci are treated with observation. Unstable discoid menisci or meniscal tears are treated with arthroscopic surgery to repair/stabilize the meniscus or debride the tear.49
Toddler’s Fracture
Fractures of the tibial shaft are common in children and adolescents, accounting for 15% of long bone fractures.52 A toddler's fracture describes a tibia shaft fracture that occurs from a low-energy twist or fall, which is why the nomenclature is trending toward childhood accidental spiral tibial fracture. Children with a developing gait will sometimes plant their lead foot and step to the side causing a rotational force on the distal tibia that leads to fracture. These are minimally or non-displaced fractures, often in a short oblique or spiral pattern on X-ray. (See Figure 4.) The fibula may or may not be fractured as well.53 A history of limping after a minor event is a common clinical presentation, and the actual traumatic injury may not have been witnessed. An initial X-ray may not show any evidence of fracture, although the evidence will appear on radiographs after 10-14 days when the healing process ensues.2 Point tenderness over the distal tibia or pain with ankle dorsiflexion on exam may be the only diagnostic finding. These fractures are treated in a long-leg splint. They most often remain non-displaced and heal in approximately four weeks with immobilization.52 Since this fracture can occur with minimal or at least unobserved trauma, there is often little history to accompany the injury. However, a toddler’s fracture is one of the few spiral fractures that does not necessarily represent an abusive injury. In a newly ambulatory child, this fracture can be reasonably explained without a corresponding history and does not necessitate a full abuse evaluation unless there are other concerning factors about the child. Between 13-43% of toddler’s fractures are not visible on initial X-rays during the index ED visit, but may be seen on subsequent X-rays 7-10 days later. The emergency provider should keep this in mind and may consider empirically placing a long-leg splint on children who limp after minor trauma.61
Figure 4. Anterior-Posterior X-ray of a Toddler’s Fracture |
 |
Juvenile Idiopathic Arthritis
Juvenile idiopathic arthritis (JIA) was previously known as juvenile rheumatoid arthritis. Ninety-seven percent of children with JIA are rheumatoid factor negative, and this is one of the reasons the name of this condition was changed.54 JIA most commonly presents in children between 2-4 years of age and 6-12 years of age, and has an initial onset at younger than 16 years of age.The onset of JIA is often insidious with persistent pain in a joint for more than six weeks and does not have another cause for arthritis. This is a diagnosis of exclusion, after a thorough history and physical have ruled out other causes of arthritis, such as septic arthritis, gonococcal arthritis, and leukemia. Laboratory data can be negative for systemic inflammation with JIA. JIA is divided into several different subtypes with systemic, oligoarticular, and polyarticular being the most common. Systemic JIA is the most pronounced form, presenting with more than two weeks of daily fever and one or more symptoms of rash, lymphadenopathy, hepatosplenomegaly, and serositis.56 Oligoarticular JIA (formerly known as pauciarticular arthritis) is the most common subset, affecting 60% of children with JIA.55 This involves four joints or less. Half of patients with oligoarticular JIA have involvement of just one joint. The knee and ankle joints are most commonly affected. Polyarticular JIA has pain in at least five joints during the first six months of the disease. This type occurs in approximately 30% of patients.55 Treatment involves NSAIDs and referral to a pediatric rheumatologist.55
Rheumatic Fever
In acute rheumatic fever, joint pain may be sudden. The patient may have one or more hot, swollen, and tender joints. There may be a history of intermittent joint pains. If fever, sore throat, elevated ESR, high ASO titer, and even carditis present, consider acute rheumatic fever in the diagnosis.54
Neoplastic Disease and Blood Dyscrasias
Symptoms concerning for neoplastic disease include night pain, weight loss, overall fatigue, night sweats, and pain at rest.59 Patients with leukemia can present with poly- or oligoarthritis, but monoarticular arthritis of the knee is actually the most common presentation.60 Severe pain out of proportion to the amount of swelling is characteristic of leukemia and can differentiate this from other causes of arthritis, such as JIA.
Acute leukemia can present with bone pain and limping in untreated and undiagnosed patients.8 The leukemic cells proliferate in the marrow and under the periosteum. Intraosseous tension is increased and causes resulting pain. Subperiosteal bleeding from thrombocytopenia can also cause raised periosteum and pain in this disease. X-rays may reveal transverse lines of reduced density below the metaphyseal ends of bones or destructive changes or periosteal elevation and new bone formation. This diagnosis is usually apparent by a peripheral blood smear.32
Henoch-SchÖnlein purpura can cause pain in the knee and ankle joints most commonly. Pain is usually not severe but can cause a limp. With this, providers will see a dependent rash on the buttocks, elbows, ankles, and adjacent dependent areas of the lower extremities. The rash can be purpuric, urticarial, and pink maculopapular. The child also may complain of abdominal pain in this circumstance.32
Sickle cell anemia can cause intravascular sickling, stasis, and thrombosis in vessels within the soft tissues or bones of the legs and can cause acute pain and limping. These children also can have associated osteomyelitis.32
With recent increased prevalence of syphilis, it must be noted that congenital syphilis can cause pain and pseudoparalysis of a limb in the early months of life. This occurs before walking. However, there may be a limp associated with one of the later manifestations of congenital syphilis, namely hydrarthrosis of the knees (Clutton’s joints).32
Intra-abdominal Pathology
The emergency medicine practitioner also should consider abdominal pathology when evaluating the child with a limp. Acute appendicitis can cause muscle spasm of the iliopsoas muscle and can refer pain into the hip or groin.32 An occult psoas abscess also could present in this way. Similarly, adolescent females may present limping from pelvic pain due to gynecologic pathology, such as pelvic inflammatory disease or ruptured ovarian cysts. These can be hard to diagnose and will require a high index of suspicion. Investigation with an MRI or CT with contrast will help evaluate these further.
Summary
The child presenting to the ED with a limp can present a diagnostic challenge for the provider. A meticulous and systematic assessment can help narrow the differential diagnosis and help guide the workup of these patients. Broken bones and muscle injuries resulting from trauma are the most commmon causes of limp in the pediatric patient, but are often evident. The minor musculoskeletal injuries, infectious, inflammatory, hematologic, and neoplastic diagnoses require a broader knowledge base and astute clinical evaluation.
REFERENCES
- Naranie S, Kelly DM, Sawyer IR. A systematic approach to the evaluation of a limping child. Am Fam Physician 2015;92:908-916.
- Herman MJ, Martinek M. The limping child. Pediatr Rev 2015;36:184-195.
- Flynn JM, Widmann RF. The limping child: Evaluation and diagnosis. J Am Acad Orthop Surg 2001;9:89-98.
- Ilharreborde B. Sequelae of pediatric osteoarticular infection. Orthop Traumatol Surg Res 2015;101:S129-137.
- McCanny PJ, McCoy S, Grant T, et al. Implementation of an evidence based guideline reduces blood tests and length of stay for the limping child in a paediatric emergency department. Emerg Med J 2013;30:19-23.
- Fischer SU, Beattie TF. The limping child: Epidemiology, assessment and outcome. J Bone Joint Surg Br 1999;81:1029-1034.
- Arnold JC, Bradley JS. Osteoarticular infections in children. Infect Dis Clin North Am 2015;29:557-574.
- Leung AK, Lemay JF. The limping child. J Pediatr Health Care 2004;18:219.
- Schoenecker JG. Pediatric hip disorders. In: Cannada LK, ed. Orthopaedic Knowledge Update: Pediatrics. 11th ed. Rosemont, IL: American Academy of Orthopaedic Surgeons; 2014; 859-875.
- Herring J, Birch J. The limping child. In: Herring J, ed. Pediatric Orthopedics. 5th ed. Philedelphia: Saunders; 2014; 79-89.
- Chung SM. Identifying the cause of acute limp in childhood: Some informal comments and observations. Clin Pediatr (Phila) 1974;13:769.
- Dabney KW, Lipton G. Evaluation of limp in children. Curr Opin Pediatr 1995;7:88.
- Fixsen JA, Valman HB. Limp in children. Br Med J (Clin Res Ed) 1981;283:780.
- Choban S, Killian JT. Evaluation of acute gait abnormalities in preschool children. J Pediatr Orthop 1990;10:74.
- Nouri A, Walmsley D, Pruszczynski B, et al. Transient synovitis of the hip: A comprehensive review. J Pediatr Orthop B 2014;23:32-36.
- Kastrissianakis K, Beattie TF. Transient synovitis of the hip: More evidence for a viral aetiology. Eur J Emerg Med 2010;17:270-273.
- Kocher MS, Zurakowski D, Kasser JR, et al. Differentiating between septic arthritis and transient synovitis of the hip in children: An evidence based clinical prediction algorithm. J Bone Joint Surg Am 1999;81:1662-1670.
- Kocher MS, Mandiga R, Murphy JM, et al. A clinical practice guideline for treatment of septic arthritis in children: Efficacy in improving process of care and effect on outcome of septic arthritis of the hip. J Bone Joint Surg Am 2003;85:994-999.
- Kocher MS, Mandiga R, Zurakowski D, et al. Validation of a clinical prediction rule for the differentiation between septic arthritis and transient synovitis of the hip in children. J Bone Joint Surg Am 2004;86-A:956-962.
- Caird MS, Flynn JM, Leung YL, et al. Factors distinguishing septic arthritis from transient synovitis of the hip in children. A prospective study. J Bone Joint Surg Am 2006;88:1251-1257.
- Sultan J, Hughes PJ. Septic arthritis or transient synovitis of the hip in children: The value of clinical prediction algorithms. J Bone Joint Surg Br 2010;92:1289-1293.
- Singhal R, Perry DC, Khan FN, et al. The use of CRP within a clinical prediction algorithm for the differentiation of septic arthritis and transient synovitis in children. J Bone Joint Surg Br 2011;93:1556-1561.
- Royle SG. Investigation of the irritable hip. J Pediatr Orthop 1992;12:396.
- Yabunaka K, Ohue M, Morimoto N, et al. Sonographic measurement of transient synovitis in children: Diagnostic value of joint effusion. Radiol Phys Technol 2012;5:15-19.
- Zamzam MM. The role of ultrasound in differentiating septic arthritis from transient synovitis of the hip in children. J Pediatr Orthop B 2006;15:418-422.
- Kwack KS, Cho JH, Lee JH, et al. Septic arthritis versus transient synovitis of the hip: Gadolinium enhanced MRI finding of decreased perfusion at the femoral epiphysis. Am J Roentgenol 2007;189:437-445.
- Kim EY, Kwack KS, Cho JH, et al. Usefulness of dynamic contrast-enhanced MRI in differentiating between septic arthritis and transient synovitis in the hip joint. Am J Roentgenol 2012;198:428-433.
- Yang WJ, Im SA, Lim GY, et al. MR imaging of transient synovitis: Differentiation from septic arthritis. Pediatr Radiol 2006;36:1154-1158.
- Dubois-Ferriere V, Belaieff W, Lascombes P, et al. Transient synovitis of the hip: Which investigations are truly useful? Swiss Med Wkly 2015;14176.
- Luhmann SJ, Jones A, Schootman M, et al. Differentiation between septic arthritis and transient synovitis of the hip in children with clinical prediction algorithms. J Bone Joint Surg Am 2004;86:956.
- Skinner J, Glancy S, Beattie TF, et al. Transient synovitis: Is there a need to aspirate hip joint effusions? Eur J Emerg Med 2002;9:15-21.
- McDonald R. Sudden acute limp in children: Some causes of a common symptom. Clin Pediatr (Phila)1967;6:571.
- Hart JJ. Transient synovitis of the hip in children. Am Fam Physician 1996;54:1587.
- Vidigal EC. Transient arthritis of the hip in children (a study of 74 cases). Ital J Orthop Traumatol 1984;10:237.
- Copley LA. Pediatric musculoskeletal infection: Trends and antibiotic recommendations. J Am Acad Orthop Surg 2009;17:618-626.
- Section J, Gibbons SD, Barton T, et al. Microbiological culture methods for pediatric musculoskeletal infection: A guideline for optimal use. J Bone Joint Surg Am 2015;97:441-449.
- Kermond S, Fink M, Graham K, et al. A randomized clinical trial: Should the child with transient synovitis of the hip be treated with non-steroidal anti-inflammatory drugs? Ann Emerg Med 2002;40:294-299.
- Fogel I, Amir J, Bar-On E, et al. Dexamethasone therapy for septic arthritis in children. Pediatrics 2015;136:e776-782.
- Kim HK. Legg-Calve-Perthes disease. J Am Acad Orthop Surg 2010;18:676-686.
- Wenger DR, Pandya NK. A brief history of Legg-Calve-Perthes disease. J Pediatr Orthop 2011;31(2 Suppl):S130-S136.
- Lahdes-Vasama T, Lamminen A, Merikanto J, et al. The value of MRI in early Perthes’ disease: An MRI study with a 2-year follow-up. Pediatr Radiol 1997;27:517.
- Aronsoon DD, Loder RT, Breur GJ, et al. Slipped capital femoral epiphysis: Current concepts. J Am Acad Orthop Surg 2006;14:666-679.
- Loder RT, Skopelia EN. The epidemiology and demographics of slipped femoral capital epiphysis. ISRN Orthop 2011;486512.
- Aronsson DD, Karol LA. Stable slipped capital femoral epiphysis: Evaluation and management. J Am Acad Orthop Surg 1996;4:173-181.
- Perry DC, Hall AJ. The epidemiology and etiology of Perthes disease. Orthop Clin North Am 2011;42:279-283.
- Beck NA, Patel NM, Ganley TJ. The pediatric knee: Current concepts in sports medicine. J Ped Orthop 2014;23:59-66.
- Carey JL, Grimm NL. Treatment algorithm for osteochondritis dissecans of the knee. Orthop Clin North Am 2015:46:141-146.
- Brown TD, et al. Meniscal injury in the skeletally immature patient. In: The Pediatric and Adolescent Knee. Philadelphia, PA: Elsevier; 2006; 236-259.
- Kramer DE, Micheli LJ. Meniscal tears and discoid meniscus in children: Diagnosis and treatment. J Am Acad Orthop Surg 2009;17:698-707.
- Jordan MR. Lateral meniscus variants: Evaluation and treatment. J Am Acad Orthop Surg 1996;4:191-200.
- Kaplan EB. Discoid lateral meniscus of the knee joint: Nature, mechanism, and operative treatment. J Bone Joint Surg Am 1957;39:77-87.
- Mashru RP, Herman MJ, Pizzutillo PD. Tibial shaft fractures in children and adolescents. J Am Acad Orthop Surg 2005;13:345-352.
- Yang JP, Letts RM. Isolated fractures of the tibia with intact fibula in children: A review of 95 patients. J Pediatr Orthop 1997;17:347-351.
- Punaro M. Rheumatologic conditions in children who may present to the orthopaedic surgeon. J Am Acad Orthop Surg 2011;19:163-169.
- Cassidy JT, Petty RE. Chronic arthritis in childhood. In: Textbook of Pediatric Rheumatology, 5th ed. Philadelphia, PA: Elsevier; 2008: 206-260.
- Weiss JE, Ilowite NT. Juvenile idiopathic arthritis. Pediatr Clin North Am 2005;52:413-442.
- Aichroth PM, Patel DV, Marx CL. Congenital discoid lateral meniscus in children: A follow-up study and evolution of management. J Bone Joint Surg Br 1991;73:932.
- Silverman JM, Mink JH, Deutsch AL. Discoid menisci of the knee: MR imaging appearance. Radiology 1989;73:351.
- Cabral DA, Tucker LB. Malignancies in children who initially present with rheumatic complaints. J Pediatr 1999;134:53-57.
- Trapani S, Grisolia F, Simonini G, et al. Incidence of occult cancer in children presenting with musculoskeletal symptoms: A 10-year survey in a pediatric rheumatology unit. Semin Arthritis Rheum 2000;29:348-359.
- Halsey MF, Finzel KC, Carrion WV, et al. Toddler’s fracture: Presumptive diagnosis and treatment. J Pediatr Orthop 2001;21:152-156.
MONOGRAPH: A focus on on the minor musculoskeletal trauma and atraumatic causes of limp and hip pain in the pediatric population.
You have reached your article limit for the month. Subscribe now to access this article plus other member-only content.
- Award-winning Medical Content
- Latest Advances & Development in Medicine
- Unbiased Content
